Methodology
Our triaxial testing follows ASTM D4767 (Consolidated-Undrained) and ASTM D7181 (Consolidated-Drained), using electromechanical load frames with 50 kN capacity and digital data acquisition. Specimens are saturated to a B-value of at least 0.95 before isotropic consolidation at effective stresses up to 10 MPa. Shearing rates are selected based on consolidation characteristics, typically 0.5%/hour for undrained tests. Consolidation testing follows ASTM D2435, with incremental loading up to 10,000 psf (480 kPa) or higher, using fixed-ring consolidometers with 2.5-inch diameter specimens. Our team also performs advanced Granulometry & Atterberg tests to classify soils before triaxial or consolidation testing.
Reference Technical Parameters
| Parameter | Reference Value |
|---|---|
| Triaxial Test Type (CU/CD) | Consolidated-Undrained / Consolidated-Drained |
| Confining Pressure Range | 20 – 1,000 kPa |
| Consolidation Load Range | 10 – 10,000 psf |
| Specimen Diameter | 1.4 – 2.8 inches |
| Shear Rate (CU) | 0.1 – 1.0 %/hour |
Local Considerations — USA
The United States presents a wide range of geotechnical conditions that affect triaxial and consolidation testing requirements. In seismic zones like Anchorage and Los Angeles, cyclic triaxial testing is often needed to evaluate liquefaction potential. In soft clay deposits along the Gulf Coast (e.g., Houston, New Orleans) and the Atlantic seaboard (e.g., Jacksonville, Norfolk), consolidation testing is critical for predicting long-term settlement. Arid regions such as Albuquerque and Phoenix require testing for collapsible soils. Our firm adapts testing protocols to local conditions, ensuring compliance with regional building codes and project-specific needs. We have performed work in Akron, Albuquerque, Allentown, Anaheim, Anchorage, Arlington, and many other cities across the country.
Request a Quote
Our team reviews your project and issues an initial report at no cost.
Or write us directly at contact@soilmechaniclaboratory.com
Applicable Standards
- ASTM D4767 – Standard Test Method for Consolidated Undrained Triaxial Compression Test for Cohesive Soils
- ASTM D7181 – Method for Consolidated Drained Triaxial Compression Test for Soils
- ASTM D2435 – Standard Test Methods for One-Dimensional Consolidation Properties of Soils
- ASCE 7 – Minimum Design Loads and Associated Criteria for Buildings and Other Structures
Frequently Asked Questions
What is the difference between consolidated-undrained (CU) and consolidated-drained (CD) triaxial tests?
In CU tests, drainage is not allowed during shearing, measuring pore pressure response, which is typical for rapid loading conditions. In CD tests, drainage is permitted, measuring effective stress strength parameters under slow loading. The choice depends on the field drainage conditions and project requirements.
How long does a typical consolidation test take?
A standard consolidation test with 6-8 load increments takes 7 to 14 days, depending on soil permeability and number of loads. Each increment requires 24 hours or until primary consolidation is complete. More permeable sands may be faster, while clays can take longer.
What standards govern triaxial and consolidation testing in the USA?
Triaxial testing follows ASTM D4767 (CU) and ASTM D7181 (CD). Consolidation testing follows ASTM D2435. Additionally, project-specific standards like AASHTO T 297 for transportation projects may apply. Our lab is accredited to these standards.
How much does triaxial and consolidation testing cost in the USA?
Costs range from $1,050 to $4,200 per test, depending on test type (CU vs. CD), number of consolidation increments, soil type, and site accessibility. Additional charges may apply for special preparation or expedited schedules. We recommend requesting a detailed quote based on your project specifications.
